Trailer Hitch For 01‑10 Chevy Silverado GMC Sierra 2500 3500 w/ Security Lock Pin Key
Model: 41944 580407 *Custom Fit Front Mount Trailer Hitch
Security Lock Pin & Key
Installation Hardware
Installation Instructions
Fits The Following Vehicles
2001 - 2010 Chevrolet, Silverado 2500 HD, All Styles
2001 - 2002 Chevrolet, Silverado 3500, All Styles
2001 - 2010 GMC, Sierra 2500 HD, All Styles
2001 - 2002 GMC, Sierra 3500, All Styles
2003 - 2007 Chevrolet, Silverado 2500 HD, (Classic)
2003 - 2007 Chevrolet, Silverado 3500, (Classic)
2003 - 2007 GMC, Sierra 2500 HD, (Classic)
2003 - 2007 GMC, Sierra 3500, (Classic)
2007 - 2010 Chevrolet, Silverado 3500 HD, All Styles
2007 - 2010 GMC, Sierra 3500 HD, All Styles
Trailer Hitch Specs:
| Part Number | 41944 |
| Brand | Draw-Tite |
| Finish | Black Powdercoat |
| Class | 5 |
| Receiver size opening | 2" |
| Max gross trailer weight | 13,000 lbs |
| Max GTW w/ weight distribution | 16,000 lbs |
| Max Tongue Weight | 1,950/1,600 lbs |
| Warranty | Lifetime |
| Installation Instructions |  |
Easy Access Lock w/Sleeve
- Includes Dust Cap
- Fits 2" and 1-7/8" Tow Receivers
- Prevents theft
- Use in place of standard pin and clip
- Easy Access Models Feature Side Key Entry, Sliding Dust Cap, Lock Housing Rotates 360 degrees.
- 1 Year Limited Warranty
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 01 02 03 04 05 06 07 08 09 10 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010
$375 63 $589.17 36% OFF
- Best Price on Web Guarantee
- Fastest Shipping
- FREE Shipping
- Pre-Order
We match lower prices from major authorized retailers for brand-new products in original packaging, provided the item is in stock. The competing seller must be an authorized, professional retail business; offers from
individuals, auctions, peer-to-peer sites, or unauthorized sellers don’t qualify. Used, refurbished, or open-box items are excluded.
Please see our full terms for details.
Verify Fitment
$589.17 $375 63
Learn more
Questions? Call our Auto Experts at (877) 869-6690
Get it now, pay later
Select installments at checkout to split your purchase into 4 interest-free payments of $93.75 every 2 weeks.
- No fees, ever.
- No impact on your credit score.
Payment options are offered by Affirm and are subject to an eligibility check and might not be available in all states. CA Residents: Loans by Affirm Loan Services, LLC are made or arranged pursuant to a California Finance Lender license.
Installments in partnership with
.
Affirm and its offerings are supported in English only. Translations are not provided by Affirm.
Product Details
- Brand: Draw-Tite
- Model: 41944 580407 *
- Includes: Ultra Frame Class 5 Trailer Tow Hitch, Trailer Tow Hitch Lock
Compatibility Chart
Description
Custom Fit Front Mount Trailer Hitch
Security Lock Pin & Key
Installation Hardware
Installation Instructions
Fits The Following Vehicles
2001 - 2010 Chevrolet, Silverado 2500 HD, All Styles
2001 - 2002 Chevrolet, Silverado 3500, All Styles
2001 - 2010 GMC, Sierra 2500 HD, All Styles
2001 - 2002 GMC, Sierra 3500, All Styles
2003 - 2007 Chevrolet, Silverado 2500 HD, (Classic)
2003 - 2007 Chevrolet, Silverado 3500, (Classic)
2003 - 2007 GMC, Sierra 2500 HD, (Classic)
2003 - 2007 GMC, Sierra 3500, (Classic)
2007 - 2010 Chevrolet, Silverado 3500 HD, All Styles
2007 - 2010 GMC, Sierra 3500 HD, All Styles
Trailer Hitch Specs:
| Part Number | 41944 |
| Brand | Draw-Tite |
| Finish | Black Powdercoat |
| Class | 5 |
| Receiver size opening | 2" |
| Max gross trailer weight | 13,000 lbs |
| Max GTW w/ weight distribution | 16,000 lbs |
| Max Tongue Weight | 1,950/1,600 lbs |
| Warranty | Lifetime |
| Installation Instructions | |
Easy Access Lock w/Sleeve
- Includes Dust Cap
- Fits 2" and 1-7/8" Tow Receivers
- Prevents theft
- Use in place of standard pin and clip
- Easy Access Models Feature Side Key Entry, Sliding Dust Cap, Lock Housing Rotates 360 degrees.
- 1 Year Limited Warranty
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 01 02 03 04 05 06 07 08 09 10 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010
Get Expert Help
Trailer Hitch For 01-10 Chevy Silverado GMC Sierra 2500 3500 w/ Security Lock Pin Key Install Notes
Installation Instructions for GMC & Chevrolet 2500HD/3500/3500HD Sierra & Silverado Trucks
Part Numbers:
- 41944
- 96944
Wiring Access Location:
- PU3
Tools Required:
- Wrenches: 13/16", 7/8", 18mm, 21mm, 22mm
- Drill Bits: None
Step-by-Step Instructions:
-
Remove Existing Bolts:
- Remove M14 bolts from the bottom of each truck frame rail’s bumper bracket.
- Return these bolts to the vehicle owner.
-
Position Hitch:
- Lift the hitch into position, aligning the rearmost slots on the hitch under the existing weldnuts in the truck frame.
-
Install Rear M14 Bolts:
- Install the new M14 bolts through lock washers, blocks, and the hitch into the weldnuts in the truck frame.
-
Remove Side Nuts and Bolt Plates:
- Remove M12 nuts and bolt plates from the sides of the frame.
- Retain these for reinstallation later.
-
Adjust Bumper Brace (2001–2007 Models):
- Loosen the nuts at the bumper end of the bumper brace, allowing it to swing away.
-
Install Attachment Bars:
- Place attachment bars as shown in the instructions and loosely bolt them to the hitch.
- For 2001–2007 models, swing the brace back and secure it as shown.
-
Install Remaining Fasteners:
- Install remaining fasteners through the existing large holes in the truck frame as shown.
- Use thinner blocks (1/4" x 3") under the hitch and orient the holes in the blocks to ensure they lay flat against the hitch when tightened.
-
Tighten Fasteners:
- Torque all M14 x 1.5 (fine-thread) fasteners to 148 lb-ft (201 N*m).
- Torque all M12 fasteners to 92 lb-ft (125 N*m).
- Torque all M14 x 2.0 (course-thread) fasteners to 148 lb-ft (201 N*m).
Torque Specifications:
- M14 x 1.5 (fine-thread): 148 lb-ft (201 N*m)
- M14 x 2.0 (course-thread): 148 lb-ft (201 N*m)
- M12 fasteners: 92 lb-ft (125 N*m)
Hardware List:
- (2) Hex Bolts, M14 x 1.5 x 45mm CL10.9
- (2) Hex Bolts, M14 x 2.0 x 60mm CL10.9
- (6) Hex Bolts, M12 x 1.75 x 45mm CL10.9
- (2) Spacer Blocks, 3/8" x 1-1/2" x 3"
- (2) Spacer Blocks, 1/4" x 1-1/2" x 3" (offset hole)
- (2) Spacer Blocks, 3/8" x 1-1/2" x 2"
- (10) Conical Washers, 1/2"
- (2) Lock Washers, 1/2"
- (2) Lock Washers, 9/16"
- (6) Nuts, M12 x 1.75 CL10
- (2) Nuts, M14 x 1.5 CL10.9
- (2) Nuts, M14 x 2.0 CL8
Safety Notes:
- Frequently check the hitch to ensure all fasteners and the ball are securely tightened.
- If the hitch is removed, plug all holes in the vehicle's frame to prevent water or exhaust fumes from entering.
- Replace any damaged hitch or ball immediately.
- Always wear eye protection and observe safety precautions when working beneath a vehicle.
- Do not cut access or attachment holes with a torch.
Specifications:
- Weight Carrying (Ball Mount):
- Max Gross Trailer Weight: 13,000 lb (5,902 kg)
- Max Tongue Weight: 1,950 lb (886 kg)
- Weight Distributing:
- Max Gross Trailer Weight: 16,000 lb (7,264 kg)
- Max Tongue Weight: 1,600 lb (726 kg)
Additional Notes:
- Complies with V.E.S.C. Regulation V-5 and SAE J684 safety standards.
- Ensure proper alignment and torque specifications are followed to maintain safety and performance.
Installation Instructions for Pickup Trucks (2500HD/3500/3500HD Models)
Part Numbers:
- 41944
- 96944
Wiring Access Location:
- PU3
Tools Required:
- Wrenches: 13/16", 7/8", 18mm, 21mm, 22mm
- Drill Bits: None
Step-by-Step Instructions:
-
Remove Existing Bolts:
- Remove M14 bolts from the bottom of each truck frame rail’s bumper bracket.
- Return these bolts to the vehicle owner.
-
Position Hitch:
- Lift the hitch into position, aligning the rearmost slots on the hitch under the existing weldnuts in the truck frame.
-
Install Rear M14 Bolts:
- Install the new M14 bolts through lock washers, blocks, and the hitch into the weldnuts in the truck frame.
-
Remove Side Nuts and Bolt Plates:
- Remove M12 nuts and bolt plates from the sides of the frame.
- Retain these for reinstallation later.
-
Adjust Bumper Brace (2001–2007 Models):
- Loosen the nuts at the bumper end of the bumper brace, allowing it to swing away.
-
Install Attachment Bars:
- Place attachment bars as shown in the instructions and loosely bolt them to the hitch.
- For 2001–2007 models, swing the brace back and secure it as shown.
-
Install Remaining Fasteners:
- Install remaining fasteners through the existing large holes in the truck frame as shown.
- Use thinner blocks (1/4" x 3") under the hitch and orient the holes in the blocks to ensure they lay flat against the hitch when tightened.
-
Tighten Fasteners:
- Torque all M14 x 1.5 (fine-thread) fasteners to 148 lb-ft (201 N*m).
- Torque all M12 fasteners to 92 lb-ft (125 N*m).
- Torque all M14 x 2.0 (course-thread) fasteners to 148 lb-ft (201 N*m).
Torque Specifications:
- M14 x 1.5 (fine-thread): 148 lb-ft (201 N*m)
- M14 x 2.0 (course-thread): 148 lb-ft (201 N*m)
- M12 fasteners: 92 lb-ft (125 N*m)
Hardware List:
- (2) Hex Bolts, M14 x 1.5 x 45mm CL10.9
- (2) Hex Bolts, M14 x 2.0 x 60mm CL10.9
- (6) Hex Bolts, M12 x 1.75 x 45mm CL10.9
- (2) Spacer Blocks, 3/8" x 1-1/2" x 3"
- (2) Spacer Blocks, 1/4" x 1-1/2" x 3" (offset hole)
- (2) Spacer Blocks, 3/8" x 1-1/2" x 2"
- (10) Conical Washers, 1/2"
- (2) Lock Washers, 1/2"
- (2) Lock Washers, 9/16"
- (6) Nuts, M12 x 1.75 CL10
- (2) Nuts, M14 x 1.5 CL10.9
- (2) Nuts, M14 x 2.0 CL8
Safety Notes:
- Frequently check the hitch to ensure all fasteners and the ball are securely tightened.
- If the hitch is removed, plug all holes in the vehicle's frame to prevent water or exhaust fumes from entering.
- Replace any damaged hitch or ball immediately.
- Always wear eye protection and observe safety precautions when working beneath a vehicle.
- Do not cut access or attachment holes with a torch.
Specifications:
- Weight Carrying (Ball Mount):
- Max Gross Trailer Weight: 13,000 lb (5,902 kg)
- Max Tongue Weight: 1,950 lb (886 kg)
- Weight Distributing:
- Max Gross Trailer Weight: 16,000 lb (7,264 kg)
- Max Tongue Weight: 1,600 lb (726 kg)
Additional Notes:
- This product complies with V.E.S.C. Regulation V-5 and SAE J684 safety standards.
- Ensure proper alignment and torque specifications are followed to maintain safety and performance.
Attention:
This is a summary of the installation procedure. For complete installation instructions, including diagrams and detailed information from the manufacturer, please download the full installation PDF.
Warranty Information:
For complete warranty instructions, please download the full installation PDF.
Technical Support:
For technical support and assistance, our team of experts is available to help. You can reach our tech support by visiting www.trailerjacks.com or calling 877-869-6690.
