Bulldog 750 lb A-Frame Trailer Jack w/ Bracket and Foot w/ 5K Collar-Lok Coupler for 2" Ball
Model: BTJC294Bulldog 750 lb A-Frame Trailer Jack with Bracket & Disc Foot + 5,000 lb Collar-Lok™ Coupler Bundle
This heavy-duty bundle combines Bulldog’s reliable 750 lb A-Frame trailer jack—complete with weld-on/bolt-on bracket and disc foot—with the industry-leading 5,000 lb Collar-Lok™ coupler. Perfect for utility, horse/livestock, cargo, and construction trailers, it delivers effortless hookup, stable support, and long-lasting performance.
Bundle Contents:
- QTY (1): Bulldog 750 lb A-Frame Trailer Jack with Bracket & Disc Foot
- 750 lb lift capacity
- A-Frame weld-on/bolt-on bracket with disc foot
- Includes Gear Box (0181550317) and Rack Post (0185200301)
- 16″ travel range
- Retracted: 3.5″ • Extended: 19.5″ • Clearance: 20.2″
- Weight: 11.1 lbs
- QTY (1): Bulldog 5,000 lb Capacity Collar-Lok™ A-Frame Coupler
- Automatic, continuously tight ball fit
- Hinged ball socket for easy hookup
- Clear visual indication of proper closure
- Strong in static and dynamic loading conditions
- Ideal for utility, horse/livestock, cargo, and construction trailers
Always verify compatibility with your trailer’s OEM specifications and perform regular maintenance—lubricate moving parts and inspect for wear before each use.
| Specifications: | |
|---|---|
| Weight Capacity | 0–1000 Pounds |
| Jack Mounting Style | A-Frame Triangular Center Mount |
| Jack Groups | A-Frame Style Trailers |
| Jack Style | A-Frame |
| Lift Mechanism | Sidewind Handle Crank |
| Jack Travel Range | 16 Inch Lift |
| Jack Finish | Silver Zinc Plated |
| Jack Static Load Capacity | 750 LB |
| Jack Foot Type | Footplate |
| Jack Leg Style | Fixed Leg |
| Jack Swivel Type | Non Swivel |
| Jack Shape | Rack / Gear Jack |
| Retracted Clearance | 3.5 Inch |
| Extended Clearance | 19.5 Inch |
| Top Clearance | 20.2 Inch |
| Electric Lift | Non Electric |
$271 99
- Best Price on Web Guarantee
- Fastest Shipping
- FREE Shipping
- Backorder (2-5 Weeks)
We match lower prices from major authorized retailers for brand-new products in original packaging, provided the item is in stock. The competing seller must be an authorized, professional retail business; offers from
individuals, auctions, peer-to-peer sites, or unauthorized sellers don’t qualify. Used, refurbished, or open-box items are excluded.
Please see our full terms for details.
$271 99
Learn more
Questions? Call our Auto Experts at (877) 869-6690
Get it now, pay later
Select installments at checkout to split your purchase into 4 interest-free payments of $ every 2 weeks.
- No fees, ever.
- No impact on your credit score.
Payment options are offered by Affirm and are subject to an eligibility check and might not be available in all states. CA Residents: Loans by Affirm Loan Services, LLC are made or arranged pursuant to a California Finance Lender license.
Installments in partnership with
.
Affirm and its offerings are supported in English only. Translations are not provided by Affirm.
Don't Miss the Next Restock!
We are working hard to bring this back. Join our VIP list to get an instant alert the second it is available.
Product Details
- Brand: Bulldog
- Model: BTJC294
- Includes: A-Frame Jack, Trailer Coupler
