Lippert Tandem Axle 3,500 lb Suspension Kit – 1.75″ Tube, 2,000 lb 26″ Leaf Springs, Tall Equalizer, Hangers & Hardware – Dexter/Alko/Rockwell Compatible
Model: LP80ASKLippert Tandem Axle 3,500 lb Suspension Kit – 1.75″ Tube
Designed for tandem axle configurations up to 3,500 lb, this complete Lippert suspension bundle includes four (3-leaf) 2,000 lb leaf springs with a nominal 26″ load length, a tall equalizer AP kit, plus front, center, and rear hangers with all necessary mounting hardware. It’s also fully compatible with Dexter, Alko, Rockwell, and Quality Axles. Enjoy improved stability and ride quality for your RV or trailer.
Bundle Contents:
- QTY (4): Lippert 2,000 lb Double-Eye Leaf Springs
- 3-leaf design, 1-3/4″ width
- Approx. 25.25″ eye-to-eye (unloaded)
- Nominal 26″ load length
- Load arch length: 1.75″
- Spring eye diameter: 9/16″
- QTY (1): Lippert Tall Equalizer AP Kit – Standard Bolts
- Equalizer Reference: EQ-310
- Includes:
- Equalizer Bolt Qty: 3 (2.88″ length)
- Shackle Assembly Qty: 4 (2.25″ length)
- Shackle Plate Qty: 4 (2.25″ length)
- Shackle Bolt Qty: 6 (2.88″ length)
- Equalizer Nut Qty: 2 (7/16″-20)
- Lock Nut Qty: 14 (7/16″-20)
- Engineered for tandem axle setups (2,000 lb – 7,000 lb)
- Helps balance road shock evenly
- QTY (2): Axle Mounting Kits – 1.75″ Tube
- U-bolt design for securing axle to springs
- Precise fit for 1.75″ axle tubes
- All necessary nuts and washers included
- QTY (2): Front Trailer Axle Hanger
- Length: 4-5/16″ | Width: 2-3/16″
- Hole size: 9/16″ | Distance to hole: 3-9/16″ on-center
- Welds to chassis for front spring placement
- QTY (2): Center Trailer Axle Hanger
- Length: 4-1/2″ | Width: 3-1/8″
- Hole size: 7/8″ | Distance to hole: 3-5/16″
- Welds to chassis for center support
- QTY (2): Rear Trailer Axle Hanger
- Length: 6″ | Width: 2-1/4″
- Hole size: 5/16″ | Distance to hole: 4″
- Welds to chassis for rear spring placement
Always confirm these components match your original equipment. Proper installation, routine inspection, and maintenance are critical for safe towing.
| Specifications: | |
|---|---|
| Kit Type | Complete Tandem Axle Suspension Kit (Hangers & Hardware Included) |
| Axle Rating | 3,500 lb |
| Leaf Spring Capacity | 2,000 lb Each |
| Number of Leaves per Spring | 3 |
| Leaf Spring Width | 1-3/4″ |
| Unloaded Eye-to-Eye Length | 25.25″ |
| Loaded Eye-to-Eye Length | 26″ (Nominal) |
| Arch Height Unloaded | ~3″ |
| Arch Height Loaded | 1.75″ |
| Spring Eye Diameter | 9/16″ |
| Axle Tube Diameter | 1.75″ |
| Equalizer Type | Tall |
| Axle Configuration | Tandem |
$345 99 $517.35 33% OFF
- Best Price on Web Guarantee
- Fastest Shipping
- FREE Shipping
- In Stock
We match lower prices from major authorized retailers for brand-new products in original packaging, provided the item is in stock. The competing seller must be an authorized, professional retail business; offers from
individuals, auctions, peer-to-peer sites, or unauthorized sellers don’t qualify. Used, refurbished, or open-box items are excluded.
Please see our full terms for details.
$517.35 $345 99
Learn more
Questions? Call our Auto Experts at (877) 869-6690
Get it now, pay later
Select installments at checkout to split your purchase into 4 interest-free payments of $ every 2 weeks.
- No fees, ever.
- No impact on your credit score.
Payment options are offered by Affirm and are subject to an eligibility check and might not be available in all states. CA Residents: Loans by Affirm Loan Services, LLC are made or arranged pursuant to a California Finance Lender license.
Installments in partnership with
.
Affirm and its offerings are supported in English only. Translations are not provided by Affirm.
Product Details
- Brand: LIPPERT
- Model: LP80ASK
- Includes: Double-Eye Leaf Spring (x4), Suspension Kit, Axle Mounting Kit (x2), Front Axle Hanger (x2), Center Axle Hanger (x2), Rear Axle Hanger (x2)
