RAM Pipe Mount Swivel Trailer Jack, Sidewind, 5,000 lb Support, 10 Inch Lift, Black, TJP-5001S-B

Model: RJ50P1S

RAM Pipe Mount Swivel Trailer Jack, Sidewind, 5,000 lb Support, 10 Inch Lift, Black, TJP-5001S-B

Built for trailer setups that need dependable lifting with a secure weld-on installation, this RAM pipe mount swivel jack delivers strong support, smooth sidewind operation, and a compact fit for demanding everyday use.

  • 5,000 lb support capacity
  • 3,000 lb lift capacity
  • 10 inches of travel
  • Sidewind handle crank
  • Swivel pipe mount
  • Black outer tube finish

Product Contents

1x RAM Pipe Mount Swivel Trailer Jack, TJP-5001S-B

Sidewind manual jack with 2-1/4 inch outer tube construction, welded zinc sand foot, grease zerk, and attached 5/8 inch pin with lanyard.

Included mounting pipe

2 inch raw round weld-on mating pipe for a secure installation point.

Recommendation

Best for dependable trailer support

This jack is a strong fit for trailers that need a manual sidewind jack with a swivel mount, sturdy weld-on installation, and reliable everyday lifting performance on uneven ground.

Built for smooth, secure operation

The grooved comfort handle, integrated grease zerk, and zinc-coated foot help keep operation controlled and maintenance simple over repeated use.

Specifications

BrandRAM
Part NumberTJP-5001S-B
Mount StylePipe Mount Swivel Jack
Lift MechanismSidewind Handle Crank
Support Capacity5,000 lb
Lift Capacity3,000 lb
Travel10 inches
Bracket Height to Center of Swivel10 inches
Retracted Height17.5 inches
Outer Tube Diameter2.25 inches
Inner Tube Diameter2 inches
Foot TypeWelded zinc sand foot, 3-3/4 x 7-1/2 inches
FinishBlack outer tube, zinc inner tube and foot
Mounting Pipe2 inch raw round weld-on mating pipe
Pin5/8 inch pin with lanyard
Maintenance FeatureIntegrated grease zerk

Need help choosing the right trailer jack? Order with confidence today, or call us at 877-869-6690 for expert support and product guidance.

$76 99

  • Best Price on Web Guarantee
  • Fastest Shipping
  • FREE Shipping
  • In Stock
Best Price on Web Guarantee
Best Price on Web Guarantee

We match lower prices from major authorized retailers for brand-new products in original packaging, provided the item is in stock. The competing seller must be an authorized, professional retail business; offers from individuals, auctions, peer-to-peer sites, or unauthorized sellers don’t qualify. Used, refurbished, or open-box items are excluded.

Please see our full terms for details.

Applies to this product only

Applies to this product only

$76 99

Pay in 4 interest-free installments of with Pay with Affirm Learn more

Questions? Call our Auto Experts at (877) 869-6690

Get it now, pay later

Select installments at checkout to split your purchase into 4 interest-free payments of $ every 2 weeks.

  • No fees, ever.
  • No impact on your credit score.

Payment options are offered by Affirm and are subject to an eligibility check and might not be available in all states. CA Residents: Loans by Affirm Loan Services, LLC are made or arranged pursuant to a California Finance Lender license.

Fits Vehicle Styles

You are in!

We will alert you the moment it is back.

Product

Don't Miss the Next Restock!

We are working hard to bring this back. Join our VIP list to get an instant alert the second it is available.

Product: Selected Item
Call us at 877-869-6690.

Product Details

  • Brand: RAM
  • Model: RJ50P1S

Default
Jack Mounting Style Pipe Mount Swivel Jack
Jack Groups Medium Duty Tailers
Weight Capacity 3001-5000 Pounds
Jack Style Pipe Mount
Lift Mechanism Sidewind Handle Crank
Jack Travel Range 10 Inch Lift
Jack Finish Black Powdercoat
Jack Static Load Capacity 5000 LB Static Capacity
Jack Lifting Load Capacity 3000 LB Lift Capacity
Jack Foot Type Footplate
Jack Leg Style Fixed Leg
Jack Swivel Type Swivel
Jack Outer Tube Diameter 2.25 Inch Outer Tube
Jack Shape Round Jack
Approx Bracket-to-Bottom Clearance (Retracted) 10 Inch
Approx Bracket-to-Bottom Clearance (Extended) 20 Inch
Electric Lift Manual Lift
Custom Bundle Yes
Exact Bracket-to-Bottom Clearance (Retracted) 10 Inch
Exact Bracket-to-Bottom Clearance (Extended) 20 Inch
Inner Tubing Diameter 2 Inch Inner Tube

Be the first to ask a question.

Write a review

Note: HTML is not translated!
Rating
Bad Good

Description

RAM Pipe Mount Swivel Trailer Jack, Sidewind, 5,000 lb Support, 10 Inch Lift, Black, TJP-5001S-B

Built for trailer setups that need dependable lifting with a secure weld-on installation, this RAM pipe mount swivel jack delivers strong support, smooth sidewind operation, and a compact fit for demanding everyday use.

  • 5,000 lb support capacity
  • 3,000 lb lift capacity
  • 10 inches of travel
  • Sidewind handle crank
  • Swivel pipe mount
  • Black outer tube finish

Product Contents

1x RAM Pipe Mount Swivel Trailer Jack, TJP-5001S-B

Sidewind manual jack with 2-1/4 inch outer tube construction, welded zinc sand foot, grease zerk, and attached 5/8 inch pin with lanyard.

Included mounting pipe

2 inch raw round weld-on mating pipe for a secure installation point.

Recommendation

Best for dependable trailer support

This jack is a strong fit for trailers that need a manual sidewind jack with a swivel mount, sturdy weld-on installation, and reliable everyday lifting performance on uneven ground.

Built for smooth, secure operation

The grooved comfort handle, integrated grease zerk, and zinc-coated foot help keep operation controlled and maintenance simple over repeated use.

Specifications

BrandRAM
Part NumberTJP-5001S-B
Mount StylePipe Mount Swivel Jack
Lift MechanismSidewind Handle Crank
Support Capacity5,000 lb
Lift Capacity3,000 lb
Travel10 inches
Bracket Height to Center of Swivel10 inches
Retracted Height17.5 inches
Outer Tube Diameter2.25 inches
Inner Tube Diameter2 inches
Foot TypeWelded zinc sand foot, 3-3/4 x 7-1/2 inches
FinishBlack outer tube, zinc inner tube and foot
Mounting Pipe2 inch raw round weld-on mating pipe
Pin5/8 inch pin with lanyard
Maintenance FeatureIntegrated grease zerk

Need help choosing the right trailer jack? Order with confidence today, or call us at 877-869-6690 for expert support and product guidance.
