Trailer Tow Hitch Hardware Fastener Kit For 16‑24 Subaru Crosstrek 18‑22 Impreza Wagon 2" Receiver Class 3
Model: HWKIT3(76209F)2016 - 2024 Subaru, Crosstrek, All Styles
2018 - 2022 Subaru, Impreza, 5 Dr. Wagon, Except WRX STi & w/Quad Exhaust Outlets
(Hardware kits ships from Mexico, it can take around 3 days for the item to ship and for tracking to be posted)
This hardware kit will only work for reinstalling the following hitch part numbers from Draw-Tite Reese and Hidden Hitch:76209 84209 76209
Installation Instructions:
Partial list of fitment years: 16 17 18 19 20 21 22 23 24 2016 2017 2018 2019 2020 2021 2022 2023 2024
$56 43 $89.21 37% OFF
- Best Price on Web Guarantee
- Fastest Shipping
- FREE Shipping
- In Stock
We match lower prices from major authorized retailers for brand-new products in original packaging, provided the item is in stock. The competing seller must be an authorized, professional retail business; offers from
individuals, auctions, peer-to-peer sites, or unauthorized sellers don’t qualify. Used, refurbished, or open-box items are excluded.
Please see our full terms for details.
Verify Fitment
$89.21 $56 43
Learn more
Questions? Call our Auto Experts at (877) 869-6690
Get it now, pay later
Select installments at checkout to split your purchase into 4 interest-free payments of $14.00 every 2 weeks.
- No fees, ever.
- No impact on your credit score.
Payment options are offered by Affirm and are subject to an eligibility check and might not be available in all states. CA Residents: Loans by Affirm Loan Services, LLC are made or arranged pursuant to a California Finance Lender license.
Installments in partnership with
.
Affirm and its offerings are supported in English only. Translations are not provided by Affirm.
Product Details
- Brand: Draw-Tite
- Model: HWKIT3(76209F)
- Includes: Hardware Kit for Class 3-5 Trailer Tow Hitch
Compatibility Chart
Description
2016 - 2024 Subaru, Crosstrek, All Styles
2018 - 2022 Subaru, Impreza, 5 Dr. Wagon, Except WRX STi & w/Quad Exhaust Outlets
(Hardware kits ships from Mexico, it can take around 3 days for the item to ship and for tracking to be posted)
This hardware kit will only work for reinstalling the following hitch part numbers from Draw-Tite Reese and Hidden Hitch:76209 84209 76209
Installation Instructions:
Partial list of fitment years: 16 17 18 19 20 21 22 23 24 2016 2017 2018 2019 2020 2021 2022 2023 2024
Get Expert Help
Trailer Tow Hitch Hardware Fastener Kit For 16-24 Subaru Crosstrek 18-22 Impreza Wagon 2" Receiver Class 3 Install Notes
Installation Instructions for Trailer Hitch #76209, #84209, and #CQT76209
Part Numbers:
- 76209
- 84209
- CQT76209
Applications:
- Years: 2018–Current
- Make and Models:
- Subaru Crosstrek
- Subaru Impreza (Hatchback)
For the most up-to-date information on application years and trim levels, consult the manufacturer’s website.
Tools Required:
- Ratchet
- Torque Wrench
- Safety Glasses
- Sockets: 11/16"
- Utility Knife
- Flat Head Screwdriver
- Exhaust Removal Pliers
- 6" Socket Extension
- Universal Joint Socket
Step-by-Step Instructions:
1. Lower the Muffler:
- Detach the (4) rearmost rubber hangers supporting the muffler using exhaust removal pliers.
- Location of Hangers:
- (2) on the left side.
- (1) on the right side.
- (1) in the middle of the vehicle.
- Tip: Apply lubricant or soapy water to ease removal. Support the exhaust system before detaching hangers.
- Location of Hangers:
2. Remove Rubber Plugs:
- Remove (2) rubber plugs from the frame holes on each side using a flat head screwdriver.
- Return plugs to the vehicle owner.
- Remove excess caulk near the access hole with a utility knife and reseal if the seam is exposed.
3. Install Fasteners:
- Feed the coiled end of the pull wire through the rearmost attachment hole and out of the forward access hole in the frame.
- Attach a 7/16" carriage bolt and spacer block to the pull wire, then pull the fasteners into position.
- Repeat for both sides using the reverse fish wire technique for additional fasteners.
4. Install Block Spacer:
- Secure the provided block spacer (Part No. 01097002) between the hitch and the frame at the access hole using tape.
5. Install the Hitch:
- Raise the hitch into position, ensuring the fasteners remain in place.
- Loosely install the conical washers (teeth side against the hitch) and hex nuts onto the carriage bolts (4 total).
6. Tighten Fasteners:
- Torque all 7/16"-14 GR5 fasteners to 50 lb-ft (68 N·m) using a torque wrench.
- Tip: Use a universal joint socket to access and tighten the rearmost bolts.
7. Raise the Muffler:
- Reattach the muffler by securing the (4) rubber hangers: (2) per side and (1) in the middle.
Hardware List:
- 4 × Pull Wires (7/16", Part No. 5481)
- 4 × Conical Tooth Washers (7/16")
- 4 × Hex Nuts (7/16"-14)
- 4 × Spacer Blocks (1/4" × 7/8" × 3", Part No. HE-2370-000)
- 4 × Carriage Bolts (7/16"-14 × 1.50")
- 2 × Block Spacers (0.250" × 1.50" × 2.00", Part No. 01097002)
Safety Notes:
- Always wear safety glasses during installation.
- Periodically check the hitch to ensure all fasteners and the hitch ball are securely tightened.
- Plug any exposed holes in the trunk pan or body panels if the hitch is removed to prevent water and exhaust fumes from entering the vehicle.
- Replace any damaged hitch or hitch ball before use.
- Do not cut access or attachment holes with a torch.
Specifications:
- Max Gross Trailer Weight (Weight Carrying): 4,500 lbs (2,043 kg)
- Max Tongue Weight (Weight Carrying): 675 lbs (306 kg)
- Weight Distribution: Not applicable
- Installation Time: Approximately 60 minutes
This product complies with V.E.S.C. Regulation V-5 and SAE J684 safety specifications for towing systems.
Technical Support:
For assistance, visit www.trailerjacks.com or call 877-869-6690.
Attention: This is a summary of the installation procedure. For complete instructions, including diagrams, please download the full installation PDF.
