Trailer Tow Hitch For 17‑24 Jaguar F‑Pace All Styles 2" Towing Receiver
Model: 760262017 - 2025 Jaguar, F-Pace, All Styles
Trailer Hitch Specs:
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 17 18 19 20 21 22 23 24 25 2017 2018 2019 2020 2021 2022 2023 2024 2025
$237 89 $371.51 36% OFF
- Best Price on Web Guarantee
- Fastest Shipping
- FREE Shipping
- In Stock

We match lower prices from major authorized retailers for brand-new products in original packaging, provided the item is in stock. The competing seller must be an authorized, professional retail business; offers from
individuals, auctions, peer-to-peer sites, or unauthorized sellers don’t qualify. Used, refurbished, or open-box items are excluded.
Please see our full terms for details.
Verify Fitment
View products that fit your vehicle
Fits 's with the following styles:
View products that fit your vehicle
Fits 's with the following styles:
$371.51 $237 89
Questions? Call our Auto Experts at (877) 869-6690
Get it now, pay later
Select installments at checkout to split your purchase into 4 interest-free payments of $59.25 every 2 weeks.
- No fees, ever.
- No impact on your credit score.
Payment options are offered by Affirm and are subject to an eligibility check and might not be available in all states. CA Residents: Loans by Affirm Loan Services, LLC are made or arranged pursuant to a California Finance Lender license.
Installments in partnership with
.
Affirm and its offerings are supported in English only. Translations are not provided by Affirm.
Product Details
- Brand: Draw-Tite
- Model: 76026
- UPC: 016118088816
- Includes: Class 4 Trailer Tow Hitch
Compatibility Chart
Year Range | Make | Model | Style |
---|
Specification | |
Attachment Location | Rear |
Ball Mount Included | No |
Color | Black |
Drilling Required | No |
Gross Towing Weight | 6,000 lbs. |
Hitch Class | IV |
Material | Steel |
Maximum Tongue Weight | 900 lbs. |
Mounting Hardware Included | Yes |
Mounting Type | Vehicle Frame |
Receiver Size | 2 in. |
Receiver Type | Square Tube |
Be the first to ask a question.
File | Size | |
---|---|---|
Trailer Hitch Instructions | 1.75MB | Download |
Description
2017 - 2025 Jaguar, F-Pace, All Styles
Trailer Hitch Specs:
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 17 18 19 20 21 22 23 24 25 2017 2018 2019 2020 2021 2022 2023 2024 2025
Get Expert Help
Trailer Tow Hitch For 17-24 Jaguar F-Pace All Styles 2" Towing Receiver Install Notes
Installation Instructions for Jaguar F-Pace (2017-Present)
Part Numbers:
- 76026
- 84026
- CQT76026
Tools Required:
- Safety Glasses
- Ratchet
- Torque Wrench
- Sockets: 8mm, 10mm, 21mm
- T20 Torx Bit
- 6" Socket Extension
- Plastic Trim Tools
- Phillips Screwdriver
- Tape Measure
- Marker
- Utility Knife
- Silicone Sealant
Weight Capacities:
- Weight Carrying:
- Max Gross Trailer Weight: 6,000 lbs (2,724 kg)
- Max Tongue Weight: 900 lbs (409 kg)
- Weight Distributing:
- Not Applicable
Installation Time:
- Estimated: 90 minutes
Step-by-Step Instructions:
1. Remove Bottom Appearance Panel:
- Use a 10mm socket to remove (3) screws and a flat head screwdriver to remove (4) plastic screws.
- Carefully remove the panel and set it aside for reinstallation.
2. Remove Fascia:
- Open the trunk and remove the plastic trim panels near the taillights.
- Use a 10mm socket to remove (1) screw behind each trim panel and a flat head screwdriver to remove (1) plastic screw on each side.
- Remove (2) screws from each wheel well and (2) T20 Torx screws and (4) plastic screws from the rear edges of the wheel well liners.
- Use trim tools to carefully unclip and remove the fascia, starting at the edges. Disconnect any wiring harnesses.
3. Remove Bumper Beam:
- Use an 8mm socket to remove (5) screws from the panel above the bumper beam.
- Use a 21mm socket to remove (4) M14 bolts from each side of the bumper beam. Remove the beam and set it aside.
4. Install Hitch:
- Apply silicone sealant around the opening on the end panels.
- Align the hitch with the bumper beam holes and loosely secure it using the (8) factory M14 bolts removed earlier.
5. Tighten Fasteners:
- Use a torque wrench to tighten all M14 fasteners to 115 lb-ft (156 N·m).
6. Trim Bottom Appearance Panel:
- Measure and mark a 6" tall by 3.5" wide area on the center of the bottom panel.
- Trim the marked section using a utility knife.
7. Reinstall Components:
- Reattach the fascia, appearance panel, and all fasteners removed earlier.
- Ensure all wiring harnesses are reconnected properly.
Safety Notes:
- Regularly check the hitch and all fasteners for proper tightness.
- If the hitch is removed, plug all holes to prevent water or exhaust fume entry.
- Replace any damaged hitch or ball immediately.
- Always wear safety glasses and observe safety precautions when working beneath a vehicle.
- Do not cut holes with a torch.
Specifications:
- Hitch Type: Class III
- Compliance: This product meets safety specifications and requirements as per V.E.S.C. Regulation V-5 and SAE J684.
Note: Always adhere to the vehicle manufacturer’s weight rating or the hitch’s maximum load rating, whichever is lower.
Installation Instructions for Vehicle Models (2017-Present)
Part Numbers:
- 76026
- 84026
- CQT76026
Tools Required:
- Safety Glasses
- Ratchet
- Torque Wrench
- Sockets: 8mm, 10mm, 21mm
- T20 Torx Bit
- 6" Socket Extension
- Plastic Trim Tools
- Phillips Screwdriver
- Tape Measure
- Marker
- Utility Knife
- Silicone Sealant
Weight Capacities:
- Weight Carrying:
- Max Gross Trailer Weight: 6,000 lbs (2,724 kg)
- Max Tongue Weight: 900 lbs (409 kg)
- Weight Distributing:
- Not Applicable
Installation Time:
- Estimated: 90 minutes
Step-by-Step Instructions:
1. Remove Bottom Appearance Panel:
- Use a 10mm socket to remove (3) screws and a flat head screwdriver to remove (4) plastic screws.
- Carefully remove the panel and set it aside for reinstallation.
2. Remove Fascia:
- Open the trunk and remove the plastic trim panels near the taillights.
- Use a 10mm socket to remove (1) screw behind each trim panel and a flat head screwdriver to remove (1) plastic screw on each side.
- Remove (2) screws from each wheel well and (2) T20 Torx screws and (4) plastic screws from the rear edges of the wheel well liners.
- Use trim tools to carefully unclip and remove the fascia, starting at the edges. Disconnect any wiring harnesses.
3. Remove Bumper Beam:
- Use an 8mm socket to remove (5) screws from the panel above the bumper beam.
- Use a 21mm socket to remove (4) M14 bolts from each side of the bumper beam. Remove the beam and set it aside.
4. Install Hitch:
- Apply silicone sealant around the opening on the end panels.
- Align the hitch with the bumper beam holes and loosely secure it using the (8) factory M14 bolts removed earlier.
5. Tighten Fasteners:
- Use a torque wrench to tighten all M14 fasteners to 115 lb-ft (156 N·m).
6. Trim Bottom Appearance Panel:
- Measure and mark a 6" tall by 3.5" wide area on the center of the bottom panel.
- Trim the marked section using a utility knife.
7. Reinstall Components:
- Reattach the fascia, appearance panel, and all fasteners removed earlier.
- Ensure all wiring harnesses are reconnected properly.
Safety Notes:
- Regularly check the hitch and all fasteners for proper tightness.
- If the hitch is removed, plug all holes to prevent water or exhaust fume entry.
- Replace any damaged hitch or ball immediately.
- Always wear safety glasses and observe safety precautions when working beneath a vehicle.
- Do not cut holes with a torch.
Specifications:
- Hitch Type: Class III
- Compliance: This product meets safety specifications and requirements as per V.E.S.C. Regulation V-5 and SAE J684.
Attention: This is a summary of the installation procedure. For complete installation instructions, including diagrams and detailed information from the manufacturer, please download the full installation PDF.
Warranty Information:
- Duration: 1-year limited warranty from the date of purchase.
- Coverage: Covers defects in materials and workmanship under normal use conditions.
For complete warranty instructions, please download the full installation PDF.
Technical Support:
For technical support and assistance, our team of experts is available to help. You can reach our tech support by visiting www.trailerjacks.com or calling 877-869-6690.
