Trailer Tow Hitch Hardware Fastener Kit For 05‑10 Jeep Grand Cherokee WK 06‑10 Commander
Model: HWKIT3(75338F)This Hitch Hardware Fastener Kit Fits The Following Vehicles:
2005 - 2010 Jeep, Grand Cherokee, Except SRT-8
2006 - 2010 Jeep, Commander, All Styles
(Hardware kits ships from Mexico, it can take around 3 days for the item to ship and for tracking to be posted)
This hardware kit will only work for reinstalling the following hitch part numbers from Draw-Tite Reese and Hidden Hitch: 75338 44748 87752 78259
Installation Instructions:
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 05 06 07 08 09 10 2005 2006 2007 2008 2009 2010
$56 48 $89.21 37% OFF
- Best Price on Web Guarantee
- Fastest Shipping
- FREE Shipping
- In Stock
We match lower prices from major authorized retailers for brand-new products in original packaging, provided the item is in stock. The competing seller must be an authorized, professional retail business; offers from
individuals, auctions, peer-to-peer sites, or unauthorized sellers don’t qualify. Used, refurbished, or open-box items are excluded.
Please see our full terms for details.
Verify Fitment
$89.21 $56 48
Learn more
Questions? Call our Auto Experts at (877) 869-6690
Get it now, pay later
Select installments at checkout to split your purchase into 4 interest-free payments of $14.00 every 2 weeks.
- No fees, ever.
- No impact on your credit score.
Payment options are offered by Affirm and are subject to an eligibility check and might not be available in all states. CA Residents: Loans by Affirm Loan Services, LLC are made or arranged pursuant to a California Finance Lender license.
Installments in partnership with
.
Affirm and its offerings are supported in English only. Translations are not provided by Affirm.
Product Details
- Brand: Draw-Tite
- Model: HWKIT3(75338F)
- Includes: Hardware Kit for Class 3-5 Trailer Tow Hitch
Compatibility Chart
| Year Range | Make | Model | Style |
|---|
Description
This Hitch Hardware Fastener Kit Fits The Following Vehicles:
2005 - 2010 Jeep, Grand Cherokee, Except SRT-8
2006 - 2010 Jeep, Commander, All Styles
(Hardware kits ships from Mexico, it can take around 3 days for the item to ship and for tracking to be posted)
This hardware kit will only work for reinstalling the following hitch part numbers from Draw-Tite Reese and Hidden Hitch: 75338 44748 87752 78259
Installation Instructions:
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 05 06 07 08 09 10 2005 2006 2007 2008 2009 2010
Get Expert Help
Trailer Tow Hitch Hardware Fastener Kit For 05-10 Jeep Grand Cherokee WK 06-10 Commander Install Notes
Installation Instructions for Jeep Grand Cherokee and Jeep Commander
Part Numbers:
- 44748
- 75338
- 87752
Applications:
- For vehicles with OEM tow hook: The tow hook must be permanently removed for hitch installation. Installation time will increase from 20 minutes to 90 minutes.
Tools Required:
- Wrenches: 3/4"
Wiring Access Location:
- SUV1, SUV2
Step-by-Step Instructions:
-
Lower Spare Tire:
- Lower the spare tire to provide clearance for hitch installation.
-
Remove Plastic Pins:
- Remove the (2) plastic pins that hold the bumper fascia onto the bumper structure (see Figure 1).
- For vehicles with an OEM tow hook, remove the fascia, plastic bumper support, and tow hook.
-
Position the Hitch:
- Gently pull the fascia rearward about 1 inch.
- Raise the hitch into position as shown in Figure 1.
-
Shim Excessive Gaps:
- If there is excessive gap between the vertical surfaces of the hitch and bumper structures, use flat washers as shims. Secure them in place with cellophane tape (see Figure 2).
-
Secure Hitch:
- Attach the hitch using the provided fasteners.
- If the fascia was removed in Step 2, reinstall the fascia and plastic bumper support.
-
Replace Plastic Pins:
- Reinsert the plastic pins into the bumper fascia.
-
Raise Spare Tire:
- Lift the spare tire back into the storage position.
-
Torque Specifications:
- Tighten all 1/2-13 GR5 fasteners with a torque wrench to 75 lb-ft (102 N·m).
Hardware List:
- (4) 1/2-13 x 4” GR5 Hex Bolts
- (8) 1/2” Flat Washers
- (4) 1/2” Conical Washers
Safety Notes:
- Check the hitch frequently to ensure all fasteners and the ball are properly tightened.
- If the hitch is removed, plug all holes in the trunk pan or other body panels to prevent water and exhaust fumes from entering.
- Replace any damaged hitch or ball immediately.
- Follow all safety precautions when working beneath the vehicle, and wear eye protection.
- Do not cut access or attachment holes with a torch.
Specifications:
- Hitch Type and Weight Ratings:
- Weight Distributing: Max Trailer Weight 7,500 lbs (3,405 kg), Max Tongue Weight 750 lbs (341 kg).
- Weight Carrying (Ball Mount): Max Trailer Weight 5,000 lbs (2,270 kg), Max Tongue Weight 750 lbs (341 kg).
- Complies with safety specifications and requirements for connecting devices and towing systems of the State of New York, V.E.S.C. Regulation V-5, and SAE J684.
Installation Instructions for Jeep Grand Cherokee and Jeep Commander
Part Numbers:
- 44748
- 75338
- 87752
Applications:
- For vehicles with OEM tow hook: The tow hook must be permanently removed for hitch installation. Installation time will increase from 20 minutes to 90 minutes.
Tools Required:
- Wrenches: 3/4"
Wiring Access Location:
- SUV1, SUV2
Step-by-Step Instructions:
-
Lower Spare Tire:
- Lower the spare tire to provide clearance for hitch installation.
-
Remove Plastic Pins:
- Remove the (2) plastic pins that hold the bumper fascia onto the bumper structure (see Figure 1).
- For vehicles with an OEM tow hook, remove the fascia, plastic bumper support, and tow hook.
-
Position the Hitch:
- Gently pull the fascia rearward about 1 inch.
- Raise the hitch into position as shown in Figure 1.
-
Shim Excessive Gaps:
- If there is excessive gap between the vertical surfaces of the hitch and bumper structures, use flat washers as shims. Secure them in place with cellophane tape (see Figure 2).
-
Secure Hitch:
- Attach the hitch using the provided fasteners.
- If the fascia was removed in Step 2, reinstall the fascia and plastic bumper support.
-
Replace Plastic Pins:
- Reinsert the plastic pins into the bumper fascia.
-
Raise Spare Tire:
- Lift the spare tire back into the storage position.
-
Torque Specifications:
- Tighten all 1/2-13 GR5 fasteners with a torque wrench to 75 lb-ft (102 N·m).
Hardware List:
- (4) 1/2-13 x 4” GR5 Hex Bolts
- (8) 1/2” Flat Washers
- (4) 1/2” Conical Washers
Safety Notes:
- Check the hitch frequently to ensure all fasteners and the ball are properly tightened.
- If the hitch is removed, plug all holes in the trunk pan or other body panels to prevent water and exhaust fumes from entering.
- Replace any damaged hitch or ball immediately.
- Follow all safety precautions when working beneath the vehicle, and wear eye protection.
- Do not cut access or attachment holes with a torch.
Attention:
This is a summary of the installation procedure. For complete installation instructions, including diagrams and detailed information from the manufacturer, please download the full installation PDF.
Technical Support:
For technical support and assistance, our team of experts is available to help. You can reach our tech support by visiting www.trailerjacks.com or calling 877-869-6690.
Warranty Information:
For complete warranty instructions, please download the full installation PDF.
