Trailer Tow Hitch Hardware Fastener Kit For 78‑95 Chevy G10 20 30 GMC G1500 2500 3500 Trailer Hitch Tow Receiver
Model: HWKIT3(41121F)1978 - 1995 Chevrolet, G10, All Styles
1978 - 1995 Chevrolet, G20, All Styles
1978 - 1995 Chevrolet, G30, All Styles
1979 - 1995 GMC, G1500, All Styles
1979 - 1995 GMC, G2500, All Styles
1979 - 1995 GMC, G3500, All Styles
1996 Chevrolet, G30, Classic & Sport Full Size w/Lo-Mount Taillights
1996 GMC, G3500, Vandura & Rally Full Size w/Lo-Mount Taillights
(Hardware kits ships from Mexico, it can take around 3 days for the item to ship and for tracking to be posted)
This hardware kit will only work for reinstalling the following hitch part numbers from Draw-Tite Reese and Hidden Hitch: 41121 87481
Installation Instructions:
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 1978 1979 1980 1981 1982 1983 1984 1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996
$56 48 $89.21 37% OFF
- Best Price on Web Guarantee
- Fastest Shipping
- FREE Shipping
- In Stock
We match lower prices from major authorized retailers for brand-new products in original packaging, provided the item is in stock. The competing seller must be an authorized, professional retail business; offers from
individuals, auctions, peer-to-peer sites, or unauthorized sellers don’t qualify. Used, refurbished, or open-box items are excluded.
Please see our full terms for details.
Verify Fitment
$89.21 $56 48
Learn more
Questions? Call our Auto Experts at (877) 869-6690
Get it now, pay later
Select installments at checkout to split your purchase into 4 interest-free payments of $14.00 every 2 weeks.
- No fees, ever.
- No impact on your credit score.
Payment options are offered by Affirm and are subject to an eligibility check and might not be available in all states. CA Residents: Loans by Affirm Loan Services, LLC are made or arranged pursuant to a California Finance Lender license.
Installments in partnership with
.
Affirm and its offerings are supported in English only. Translations are not provided by Affirm.
Product Details
- Brand: Draw-Tite
- Model: HWKIT3(41121F)
- Includes: Hardware Kit for Class 3-5 Trailer Tow Hitch
Compatibility Chart
| Year Range | Make | Model | Style |
|---|
Description
1978 - 1995 Chevrolet, G10, All Styles
1978 - 1995 Chevrolet, G20, All Styles
1978 - 1995 Chevrolet, G30, All Styles
1979 - 1995 GMC, G1500, All Styles
1979 - 1995 GMC, G2500, All Styles
1979 - 1995 GMC, G3500, All Styles
1996 Chevrolet, G30, Classic & Sport Full Size w/Lo-Mount Taillights
1996 GMC, G3500, Vandura & Rally Full Size w/Lo-Mount Taillights
(Hardware kits ships from Mexico, it can take around 3 days for the item to ship and for tracking to be posted)
This hardware kit will only work for reinstalling the following hitch part numbers from Draw-Tite Reese and Hidden Hitch: 41121 87481
Installation Instructions:
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 78 79 80 81 82 83 84 85 86 87 88 89 90 91 92 93 94 95 96 1978 1979 1980 1981 1982 1983 1984 1985 1986 1987 1988 1989 1990 1991 1992 1993 1994 1995 1996
Get Expert Help
Trailer Tow Hitch Hardware Fastener Kit For 78-95 Chevy G10 20 30 GMC G1500 2500 3500 Trailer Hitch Tow Receiver Install Notes
Installation Instructions for Chevrolet & GMC Vans
Part Numbers:
- 41121
- 87481
Wiring Access Location:
- Not specified
Tools Required:
- Ratchet
- Torque Wrench
- 9/16" Wrench and Socket
- 3/4" Wrench and Socket
Installation Time:
- Estimated: Not specified
Step-by-Step Instructions:
-
Remove Bumper Support Brackets:
- Remove the two lower bumper support brackets (one per side).
- Save the bolts and washers.
- Return the brackets to the vehicle owner.
-
Install Side Brackets:
- Place the left and right side brackets against the bottom of the vehicle frame.
- Attach with four (4) 1/2" bolts and washers removed in Step 1.
- Leave the bolts loose for now.
-
Install Bumper Bolts:
- Install two (2) 3/8" bumper bolts (removed in Step 1), along with two (2) 3/8" serrated washers and two (2) 3/8" lock nuts (provided in the parts package).
- Leave the lock nuts loose at this time.
Warning:
- Two 3/8" lock nuts must be used with two 3/8" bumper bolts to ensure the receiver does not loosen or separate from the vehicle.
-
Fishwire Carriage Bolts:
- Screw the pull wire onto a 1/2" carriage bolt.
- Feed the pull wire through a bolt plate and the large hole in the outboard side of the frame.
- Pull it out through the bottom hole of the frame.
- Repeat for the other side.
- Install two (2) 1/2" serrated washers, lock washers, and nuts on the bolts.
- Leave the nuts loose at this time.
-
Tighten Bolts and Nuts:
- Tighten bolts and nuts in the following order to ensure proper alignment:
- Torque the two (2) 3/8" lock nuts on the bumper to 30 ft-lb.
- Torque the 1/2" nuts and bolts to 75 ft-lb.
- Tighten bolts and nuts in the following order to ensure proper alignment:
Torque Specifications:
- 3/8" lock nuts: 30 ft-lb
- 1/2" nuts and bolts: 75 ft-lb
Hardware List:
- (4) 1/2" Carriage Bolts
- (4) 1/2" Serrated Washers
- (4) 1/2" Nuts
- (4) Bolt Plates
- (2) 3/8" Bumper Bolts
- (2) 3/8" Serrated Washers
- (2) 3/8" Lock Nuts
- (1) 1/2" Pull Wire
Safety Notes:
- Do not lubricate threads, as bolt failure may occur due to over-tightening.
- Do not drill or weld to this hitch.
- Regularly check the hitch to ensure all fasteners are tight and properly installed.
Specifications:
- Weight Carrying:
- Max Gross Trailer Weight: 5,000 lb
- Max Tongue Weight: 500 lb
- Weight Distributing:
- Max Gross Trailer Weight: 10,000 lb
- Max Tongue Weight: 1,000 lb
Additional Notes:
- Use only bolts, lock nuts, and washers supplied or approved by Towing Products for installation.
- This product complies with VESC regulation V-5 and is certified for safety specifications in New York State.
Installation Instructions for Vans
Part Numbers:
- 41121
- 87481
Wiring Access Location:
- Not specified
Tools Required:
- Ratchet
- Torque Wrench
- 9/16" Wrench and Socket
- 3/4" Wrench and Socket
Installation Time:
- Estimated: Not specified
Step-by-Step Instructions:
-
Remove Bumper Support Brackets:
- Remove the two lower bumper support brackets (one per side).
- Save the bolts and washers.
- Return the brackets to the vehicle owner.
-
Install Side Brackets:
- Place the left and right side brackets against the bottom of the vehicle frame.
- Attach with four (4) 1/2" bolts and washers removed in Step 1.
- Leave the bolts loose for now.
-
Install Bumper Bolts:
- Install two (2) 3/8" bumper bolts (removed in Step 1), along with two (2) 3/8" serrated washers and two (2) 3/8" lock nuts (provided in the parts package).
- Leave the lock nuts loose at this time.
Warning:
- Two 3/8" lock nuts must be used with two 3/8" bumper bolts to ensure the receiver does not loosen or separate from the vehicle.
-
Fishwire Carriage Bolts:
- Screw the pull wire onto a 1/2" carriage bolt.
- Feed the pull wire through a bolt plate and the large hole in the outboard side of the frame.
- Pull it out through the bottom hole of the frame.
- Repeat for the other side.
- Install two (2) 1/2" serrated washers, lock washers, and nuts on the bolts.
- Leave the nuts loose at this time.
-
Tighten Bolts and Nuts:
- Tighten bolts and nuts in the following order to ensure proper alignment:
- Torque the two (2) 3/8" lock nuts on the bumper to 30 ft-lb.
- Torque the 1/2" nuts and bolts to 75 ft-lb.
- Tighten bolts and nuts in the following order to ensure proper alignment:
Torque Specifications:
- 3/8" lock nuts: 30 ft-lb
- 1/2" nuts and bolts: 75 ft-lb
Hardware List:
- (4) 1/2" Carriage Bolts
- (4) 1/2" Serrated Washers
- (4) 1/2" Nuts
- (4) Bolt Plates
- (2) 3/8" Bumper Bolts
- (2) 3/8" Serrated Washers
- (2) 3/8" Lock Nuts
- (1) 1/2" Pull Wire
Safety Notes:
- Do not lubricate threads, as bolt failure may occur due to over-tightening.
- Do not drill or weld to this hitch.
- Regularly check the hitch to ensure all fasteners are tight and properly installed.
Specifications:
- Weight Carrying:
- Max Gross Trailer Weight: 5,000 lb
- Max Tongue Weight: 500 lb
- Weight Distributing:
- Max Gross Trailer Weight: 10,000 lb
- Max Tongue Weight: 1,000 lb
Additional Notes:
- Use only bolts, lock nuts, and washers supplied or approved by Towing Products for installation.
- This product complies with VESC regulation V-5 and is certified for safety specifications in New York State.
Attention:
This is a summary of the installation procedure. For complete installation instructions, including diagrams and detailed information from the manufacturer, please download the full installation PDF.
Technical Support:
For technical support and assistance, our team of experts is available to help. You can reach our tech support by visiting www.trailerjacks.com or calling 877-869-6690.
Warranty:
This product is covered by a limited warranty. For complete warranty instructions, please download the full installation PDF.
