Trailer Tow Hitch Hardware Fastener Kit For 07‑12 KIA Rondo 1‑1/4" Towing Receiver Class 1
Model: HWKIT1(24797F)This Hitch Hardware Fastener Kit Fits The Following Vehicles:
2007 - 2010 KIA, Rondo, All Styles
2011 - 2012 KIA, Rondo, (Canada Only)
(Hardware kits ships from Mexico, it can take around 3 days for the item to ship and for tracking to be posted)
This hardware kit will only work for reinstalling the following hitch part numbers from Draw-Tite Reese and Hidden Hitch: 24797 60874 77169 24915
Installation Instructions:
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 07 08 09 10 11 12 2007 2008 2009 2010 2011 2012
$39 59 $44.64 11% OFF
- Best Price on Web Guarantee
- Fastest Shipping
- FREE Shipping
- In Stock
We match lower prices from major authorized retailers for brand-new products in original packaging, provided the item is in stock. The competing seller must be an authorized, professional retail business; offers from
individuals, auctions, peer-to-peer sites, or unauthorized sellers don’t qualify. Used, refurbished, or open-box items are excluded.
Please see our full terms for details.
Verify Fitment
$44.64 $39 59
Learn more
Questions? Call our Auto Experts at (877) 869-6690
Get it now, pay later
Select installments at checkout to split your purchase into 4 interest-free payments of $9.75 every 2 weeks.
- No fees, ever.
- No impact on your credit score.
Payment options are offered by Affirm and are subject to an eligibility check and might not be available in all states. CA Residents: Loans by Affirm Loan Services, LLC are made or arranged pursuant to a California Finance Lender license.
Installments in partnership with
.
Affirm and its offerings are supported in English only. Translations are not provided by Affirm.
Product Details
- Brand: Draw-Tite
- Model: HWKIT1(24797F)
- Includes: Hardware Kit for Class 1 Trailer Tow Hitch
Compatibility Chart
Description
This Hitch Hardware Fastener Kit Fits The Following Vehicles:
2007 - 2010 KIA, Rondo, All Styles
2011 - 2012 KIA, Rondo, (Canada Only)
(Hardware kits ships from Mexico, it can take around 3 days for the item to ship and for tracking to be posted)
This hardware kit will only work for reinstalling the following hitch part numbers from Draw-Tite Reese and Hidden Hitch: 24797 60874 77169 24915
Installation Instructions:
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 07 08 09 10 11 12 2007 2008 2009 2010 2011 2012
Get Expert Help
Trailer Tow Hitch Hardware Fastener Kit For 07-12 KIA Rondo 1-1/4" Towing Receiver Class 1 Install Notes
Installation Instructions for Kia Rondo
Part Numbers:
- 60874
- 24797
- 77169
Wiring Access Location:
- SUV1
- SUV2
Tools Required:
- Wrenches: 10 mm, 12 mm, 13 mm, 14 mm, 17 mm
- Drill Bits: None
Step-by-Step Instructions:
-
Lower Exhaust:
- Disconnect the muffler from the rubber exhaust hangers in three locations.
-
Remove Heat Shield:
- Temporarily remove the exhaust heat shield.
- Retain the heat shield and fasteners for reinstallation after the hitch is installed.
-
Remove Tie-Down Hook:
- On the driver's side, remove the tie-down hook.
- Return the tie-down hook and fasteners to the vehicle owner.
-
Prepare Frame Rail:
- Remove the fasteners at the end of the frame rail as shown in the illustration. Discard these fasteners.
-
Install Hitch:
- Raise the hitch into position and secure it using the provided fasteners into the existing weldnuts on the frame rail.
- Tighten all M8 CL8.8 fasteners to 20 lb-ft (27 N*m).
- Tighten all M10 CL8.8 fasteners to 38 lb-ft (52 N*m).
-
Reinstall Heat Shield:
- Reattach the exhaust heat shield using the retained fasteners.
-
Raise Exhaust:
- Reconnect the muffler to the rubber exhaust hangers.
Hardware List:
- (2) Hex Bolt M10 x 1.25 x 40 mm CL8.8
- (3) Hex Bolt M8 x 1.25 x 30 mm CL8.8
- (2) Conical Washer 7/16"
- (3) Conical Washer 3/8"
Safety Notes:
- Check the hitch frequently to ensure all fasteners and the ball are properly tightened.
- If the hitch is removed, plug all holes in the trunk pan or other body panels to prevent water or exhaust fumes from entering.
- Replace any damaged hitch or ball immediately.
- Observe safety precautions when working beneath the vehicle and wear eye protection.
- Do not cut access or attachment holes with a torch.
Specifications:
- Weight Carrying Capacity: 2,000 lbs (908 kg) trailer weight, 200 lbs (91 kg) tongue weight.
- Weight Distributing Capacity: Not applicable.
- Drawbar must be used in the rise position only.
- Product complies with V.E.S.C. Regulation V-5 and SAE J684.
Additional Notes:
- Installation time for professional installers is approximately 30 minutes.
- For further details, refer to the QR code or website provided in the full manual.
