Trailer Hitch Hardware Fastener Kit for 07‑11 Honda CR‑V 1‑1/4" Towing Receiver Class 1
Model: HWKIT1(24792F)2007 - 2011 Honda, CR-V, All Styles
(Hardware kits ship from Mexico, it can take around 3 days for the item to ship and for tracking to be posted)
This hardware kit will only work for reinstalling the following hitch part numbers from Draw-Tite Reese and Hidden Hitch: 24792 77147 60869
Installation Instructions:
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 07 08 09 10 11 2007 2008 2009 2010 2011
$39 59 $44.64 11% OFF
- Best Price on Web Guarantee
- Fastest Shipping
- FREE Shipping
- In Stock
We match lower prices from major authorized retailers for brand-new products in original packaging, provided the item is in stock. The competing seller must be an authorized, professional retail business; offers from
individuals, auctions, peer-to-peer sites, or unauthorized sellers don’t qualify. Used, refurbished, or open-box items are excluded.
Please see our full terms for details.
Verify Fitment
$44.64 $39 59
Learn more
Questions? Call our Auto Experts at (877) 869-6690
Get it now, pay later
Select installments at checkout to split your purchase into 4 interest-free payments of $9.75 every 2 weeks.
- No fees, ever.
- No impact on your credit score.
Payment options are offered by Affirm and are subject to an eligibility check and might not be available in all states. CA Residents: Loans by Affirm Loan Services, LLC are made or arranged pursuant to a California Finance Lender license.
Installments in partnership with
.
Affirm and its offerings are supported in English only. Translations are not provided by Affirm.
Product Details
- Brand: Draw-Tite
- Model: HWKIT1(24792F)
- Includes: Hardware Kit for Class 1 Trailer Tow Hitch
Compatibility Chart
Description
2007 - 2011 Honda, CR-V, All Styles
(Hardware kits ship from Mexico, it can take around 3 days for the item to ship and for tracking to be posted)
This hardware kit will only work for reinstalling the following hitch part numbers from Draw-Tite Reese and Hidden Hitch: 24792 77147 60869
Installation Instructions:
Thank you for choosing Draw Tite the most powerful name in towing industry bar none. Manufactured by the same people that brought you Reese and Hidden Hitch all of our products come with standard lifetime warranty and support. Our custom hitches mount easily on your Car Truck Van SUV and RV. Most applications simply bolt on without any need for drilling or modifying your bumper. Please review installation instructions manual pdf file above for exact step by step instructions. Chose Class 1 or 2 for light duty towing, chose Class 3 4 and 5 for heavy duty towing. Pair your hitch with accessories like a ball mount that is available in several drop and rise configurations. Choose a 2 inch ball to haul most standard trailers. Choose a 1-7/8" ball to tow small and u tility trailers. Our hitches come with generous tongue weight ratings for use with cargo racks and other accessories. All parts in our store are sold at a discount. If you have any questions please do not hesitate to give us a call at 702-374-8999
Partial list of fitment years: 07 08 09 10 11 2007 2008 2009 2010 2011
Get Expert Help
Trailer Hitch Hardware Fastener Kit for 07-11 Honda CR-V 1-1/4" Towing Receiver Class 1 Install Notes
Installation Instructions for Honda Accord Sedan and Acura 3.2 CL & TL
Part Numbers:
- 60913
- 24791
- 77165
Wiring Access Location:
- PC3
Tools Required:
- Wrenches: 3/4”
- Drill Bits: None
Specifications:
- Max Gross Trailer Weight: 2,000 lb. (908 kg)
- Max Tongue Weight: 200 lb. (90.8 kg)
- Note: Do not exceed towing vehicle manufacturer’s rating.
Step-by-Step Instructions:
-
Lower Exhaust:
- Remove the rubber isolators from the muffler hangers to lower the exhaust.
-
Prepare Bolt and Plate Assembly:
- Thread the bolt leader onto the 1-1/2” carriage bolt and insert it through the hole in the reinforcing plate.
- Fishwire the bolt leader and assembly through the access hole in the bottom of the frame and pull it through the proper hole in the frame.
- Repeat for the other side.
-
Position Hitch:
- Raise the hitch into position.
- Insert the 2” carriage bolt along with the square hole spacer, round hole spacer, and hitch's mounting tab through the vehicle's tie-down hook in the order shown in the illustration.
- Install the conical toothed washer and nut and hand-tighten to hold the hitch in place.
-
Attach Hitch to Frame Straps:
- Fishwire the bolt leaders through the holes in the frame straps.
- Carefully remove the bolt leaders without pushing the bolt assemblies back into the frame channels.
- Install conical toothed washers and nuts.
-
Tighten Fasteners:
- Use a torque wrench to tighten all 1/2”-13 GR5 fasteners to 75 Lb.-Ft. (102 N*M).
-
Reinstall Exhaust:
- Raise the exhaust back into position and reattach the rubber isolators.
Hardware List:
- (2) Carriage Bolts: 1/2”-13 x 1-1/2” GR5
- (2) Reinforcing Plates: 1” x 3” x 1/4”
- (2) Bolt Leaders
- (3) Conical Toothed Washers: 1/2”
- (3) Nuts: 1/2”-13 GR5
- (1) Carriage Bolt: 1/2”-13 x 2-1/2”
- (1) Square Hole Spacer: 1” x 2” x 1/4”
- (1) Round Hole Spacer: 1” x 2” x 1/4”
Safety Notes:
- Regularly inspect all fasteners and the hitch ball to ensure proper tightening.
- If the hitch is removed, plug any holes in the trunk pan or other body panels to prevent water and exhaust fumes from entering.
- Replace any damaged hitch or ball immediately.
- Always wear safety glasses when working beneath the vehicle.
- Do not use a torch to cut access or attachment holes.
Drawbar:
- Drawbar Kit: 3592
- Important: The drawbar must be used in the rise position only.
Compliance:
- This product complies with SAE J684, V.E.S.C. Regulation V-5, and safety requirements of the State of New York.
Additional Notes:
- Check the hitch frequently to ensure all fasteners remain tight.
- If required, modify the frame access hole using the recommended procedures to ensure hardware fits through.
Installation Instructions for Various Vehicles
Part Numbers:
- 60913
- 24791
- 77165
Wiring Access Location:
- PC3
Tools Required:
- Wrenches: 3/4”
- Drill Bits: None
Specifications:
- Max Gross Trailer Weight: 2,000 lb. (908 kg)
- Max Tongue Weight: 200 lb. (90.8 kg)
- Note: Do not exceed towing vehicle manufacturer’s rating.
Step-by-Step Instructions:
-
Lower Exhaust:
- Remove the rubber isolators from the muffler hangers to lower the exhaust.
-
Prepare Bolt and Plate Assembly:
- Thread the bolt leader onto the 1-1/2” carriage bolt and insert it through the hole in the reinforcing plate.
- Fishwire the bolt leader and assembly through the access hole in the bottom of the frame and pull it through the proper hole in the frame.
- Repeat for the other side.
-
Position Hitch:
- Raise the hitch into position.
- Insert the 2” carriage bolt along with the square hole spacer, round hole spacer, and hitch's mounting tab through the vehicle's tie-down hook in the order shown in the illustration.
- Install the conical toothed washer and nut and hand-tighten to hold the hitch in place.
-
Attach Hitch to Frame Straps:
- Fishwire the bolt leaders through the holes in the frame straps.
- Carefully remove the bolt leaders without pushing the bolt assemblies back into the frame channels.
- Install conical toothed washers and nuts.
-
Tighten Fasteners:
- Use a torque wrench to tighten all 1/2”-13 GR5 fasteners to 75 Lb.-Ft. (102 N*M).
-
Reinstall Exhaust:
- Raise the exhaust back into position and reattach the rubber isolators.
Hardware List:
- (2) Carriage Bolts: 1/2”-13 x 1-1/2” GR5
- (2) Reinforcing Plates: 1” x 3” x 1/4”
- (2) Bolt Leaders
- (3) Conical Toothed Washers: 1/2”
- (3) Nuts: 1/2”-13 GR5
- (1) Carriage Bolt: 1/2”-13 x 2-1/2”
- (1) Square Hole Spacer: 1” x 2” x 1/4”
- (1) Round Hole Spacer: 1” x 2” x 1/4”
Safety Notes:
- Regularly inspect all fasteners and the hitch ball to ensure proper tightening.
- If the hitch is removed, plug any holes in the trunk pan or other body panels to prevent water and exhaust fumes from entering.
- Replace any damaged hitch or ball immediately.
- Always wear safety glasses when working beneath the vehicle.
- Do not use a torch to cut access or attachment holes.
Drawbar:
- Drawbar Kit: 3592
- Important: The drawbar must be used in the rise position only.
Compliance:
- This product complies with SAE J684, V.E.S.C. Regulation V-5, and safety requirements of the State of New York.
Additional Notes:
- Check the hitch frequently to ensure all fasteners remain tight.
- If required, modify the frame access hole using the recommended procedures to ensure hardware fits through.
Additional Information:
- Attention: This is a summary of the installation procedure. For complete installation instructions, including diagrams and detailed information from the manufacturer, please download the full installation PDF.
Technical Support:
- For technical support and assistance, our team of experts is available to help. You can reach our tech support by visiting www.trailerjacks.com or calling 877-869-6690.
Warranty:
- For complete warranty instructions, please download the full installation PDF.
